Features • Complies with the next generation IEEE 802.11ac Wi-Fi standard • Simultaneous 1733Mbps on 5GHz and 800Mbps on 2.4GHz for a total of 2533Mbps • MU-MIMO technology allows to transfer data to multiple devices at the same time • Beamforming focuses Wi-Fi signals & delivers stronger connections for mobile devices • Five Gigabit port s ensure high-speed Internet access and wired speed • 8 high power antennas provide wider coverage throughout your home • Dual Core MIPS Processor boosts wireless and wired performance • Supports DHCP, Static IP, PPPoE, PPTP and L2TP broadband functions Hardware Features Interface: 4 x 1000Mbps LAN Ports | 1 x 1000Mbps WAN Port Power Supply: 12V DC / 1.5A Button: 1 *RST/WPS Button LED Indicator: 1 * SYSTEM LED Antenna: 4 * 5dBi fixed antennas (2.4G), 4 * 5dBi fixed antennas (5G) Dimensions (L x W x H): 27.4 x 18.2 x 6.1 cm Wireless Features Standards: IEEE 802.11ac, IEEE 802.11a, IEEE 802.11b, IEEE 802.11g ,IEEE 802.11n RF Frequency: 2.4GHz/5GHz EIRP: 2.4GHz < 22dBm | 5GHz < 20dBm Data Rate: 22.4GHz: Up to 800Mbps 5GHz: Up to 1733Mbps Wireless Security: 64/128-bit WEP, and WPA2 Reception Sensitivity: 2.4G: 11b 11M:-81dBm@8% PER 11g 54M: -68dBm@10% PER 11n HT20 MCS7:-65dBm@10% PER HT40 MCS7:-62dBm@10% PER 5G: 11a 54M: -68dBm@10% PER 11n HT20 MCS7:-65dBm@10% PER HT40 MCS7:-62dBm@10% PER 11ac VHT80 MCS9:-51dBm@10% PER Software Features Opearation Mode: Gateway Mode | Bridge Mode | Repeater Mode | WISP Mode WAN Type: DHCP/Static IP/PPPoE/PPTP/L2TP Wireless Functions: Multiple SSIDs, MAC Authentication, Universal Repeater, WDS,WPS, IPTV Schedule: Reboot Schedule, Wireless Schedule Firewall: MAC Filtering, IP Filtering, Port Filtering, URL Filtering Port Forwarding, DMZ Management: QoS, DDNS, remote management, and more. Other Information Environment: Operating Temperature: 0℃~50 ℃ (32 ℉~122℉) Storage Temperature: -40℃~70 ℃ (-40 ℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing
